  1. 1/3 Sony Effio-E 700TVL Single layer IR sensor OSD Board Camera

  2. 1/3 Sony Effio-E 700TVL Single layer IR sensor OSD Board Camera


    Condition:New
    Scheme:673+4140


  3. Features:

    1/3 Sony Effio-E 700TVL Single layer IR sensor OSD Board Camera
    CCD: 1/3 Sony EXview HAD CCD II" Sensor effio DSP
    Size: 38mm*38mm
    pixel: PAL: 1020H¡Á596V (0.6megapixel) NTSC: 1020H¡Á508V (0.5megapixel)
    effective pixel: PAL: 976H¡Á582V (0.57megapixel) NTSC: 976H¡Á494V
    system: PAL/NTSC
    Resolution: 700TVL
    Digital Noise Reduce: 2DNR, support 0~15 16levels adjust
    OSD : support
    Low illumination: 0.01LUX/F1.2
    S/N: ¡Ý48dB
    Video output: 1.0Vp-p/75¦¸
    AGC: 0.25/0.50/0.75/1.00 4 level adjust max: 55dB
    White balance: open/Close
    BLC: HLC/ BLC
    Electronic shutter: 1/50(1/60) - 1/100000 Ãë
    Gama: 0.45/1.0
    Audio: option
    Working Voltage: DC12V¡À5%
    Working temprature: (-20¡æ--60¡æ)
    Humidity: 0%¡«96%
