This is the latest 600TVL board camera with Sony HAD CCD chipset which produces high quality image. It is of high value/cost ratio.
Imaging Sensor | 1/3" SONY SUPER HAD CCD | |
Horizontal Resolution | 600TVL (2040+639) | |
TV System | PAL/NTSC | |
Effective Pixel | PAL:752(H)*582(V), NTSC:768(H)*494(V) | |
Sync System | Internal | |
Mini Illumination | 0.5Lux/F1.2 , 0.01Lux/F1.2 | |
White Balance | Model | AUTO |
Range | 3200~10000K | |
Gain Control | AUTO | |
S/N Ratio | >=52dB | |
Electronic Shutter | 1/50~1/12,000 second | |
Video Output | Composite output 1.0Vp-p at 75 ohm | |
Gamma Correction | >0.45 | |
Operation Temp | -10C~50C | |
Dimensions | 38mmX38mm | |
Power | DC12V | |
weight | 45g |
