  1. H-series intelligent High Speed Dome Camera

  2. H-series intelligent High Speed Dome Camera

    CCD outdoor High Speed Dome Camera


    Model: BT-HH2

    Place of Origin: Guangdong China (Mainland)




  3. Specifications:

    1) outdoor high speed dome camera
    2) 1 year warranty
    3) 360 degree rotation
    4) CE and FCC etc
    5) life time maintainance

    Key Feature:
     * Full aluminum design, can dissipate heat more sufficiently; Black inner-shell makes sharper monitor
     * Built in OSD menu and support inputting with Chinese or English; Display or set parameter via menu.
     * Auto-identify various SONY, HITACHI, LG, CNB, SAMSUNG, YOKO, etc, and auto read camera model when power on.
     * The first designer of wide voltage in domestic, DC12V~AC24V, no need to identify "+" or "-".
     * Soft address design can alter long-distance ID address code, no need manual dial-up.
     * Show and Edit title function containing 20 English letters, can independently set the titles for camera itself Preset Position, Patten Scan, Auto-level Scan and Zone display.
     * Auto flip with vertical 180°„ in omni-directions, no fade zone
     * 200 preset positions and titles can be set.
     * 4 patrol tracking routes, every can insert 32 spots
     * 4 patterns scan routes and continuous track record of 1000 in action, time of up to 10 minutes£Ľ
     * 4 auto levels scan routes with left & right spacing; Speed can be set.
     * Position-indicating function, temperature indicator function (Celsius / Fahrenheit simultaneous display), information display, information inquiry function.
     * 8 dynamic privacy zone can be setup.
     * 8 display zones with editable title.
     * Alarm system with 4input and 2 output channel and support the linkage ( recall preset and various of scan mode. Tracking. Pattern. Auto-level scan)
     * Auto activation at fixed time, and can auto execute different scans and presets after a given leisure time.
     * RS485 control, integrated various of protocols, PELCO-D, PELCO-P, KALATEL, AD, PHILIPS, SAE, VCL etc..
     * Built-in temperature-controlled heating system and the speed fan
     * 3 class lightning defend, built in 3000V lightning proof, surge resistant.
     * IP 66 outer cover with all day protection.



    Power input DC12V~AC24V (°ņ10%)
    Power consumption Indoor°‹12W,outdoor°‹45W
    Image sensor 1/4 inch SONY SUPER HAD CCD
    Signal mode PAL/NTSC
    Preset position 200 presets, title settable
    Accuracy °ņ0.1º
    Pan rotation range 360ºContinuous Rotation, 0.5º-240º/S
    Tilt rotation range 90ºVertical, 180ºAuto flip, 0.5º-220°„/S
    Control method RS485/Mancherster/BI-PHASE code
    Protocol Pelco-P/D,AD,PHILIPS etc
    Working temperature Indoor:0ºC ~ 50ºC,Outdoor:-40ºC ~60ºC
    Ambient humidity 0-95%Non-condensing
    Shell material Aluminum
    Installation Wall, Pendant, Pole, Corner
