  1. O series outdoor Intelligent High Speed Dome Camera

  2. O series outdoor Intelligent High Speed Dome Camera

    CCD Outdoor High Speed Dome Camera


    Model: BT-HO

    Place of Origin: Guangdong China (Mainland)






  3. Key Features:
    * Fast installation structure design, can install easily and quickly; Double layer of Die-cast Aluminum shell, can dissipate heat more sufficiently. Black inner shell makes sharper monitor
    * Built-in OSD menu in English, support 20 English letters input; Display or set parameter via menu.
    * Auto-identify various SONY, HITACHI, LG, CNB, SAMSUNG, etc, and auto read camera model when power on.
    * The first designer of wide voltage in domestic, DC12V~AC24V, no need to identify °į+°Ī or °į-°Ī;
    * Soft address design can alter long-distance ID address code, no need manual dial-up.
    * Show and Edit title function containing 20 English letters, can independently set the titles for camera itself, Preset Position, Pattern Scan, Auto-level Scan and Zone display.
    * Auto flip with vertical 180°„ in Omni-directions, no fade zone.
    * 200 preset position with editable title; 4 patrol tracking routes, each can insert 32 spots.
    * 4 Pattern scan routes, each can record 1000 consecutive moves, the time up to 10 minutes.
    * 4 auto levels scan routes with left & right spacing, speed can set.
    * Position-indicating function, temperature indicator function, information display function, information query function
    * 8 dynamic privacy zone can setup.
    * 8 display zones with editable title.
    * Alarm system with 4 input and 2 output channel and support the linkage (recall presets and various of scan mode. Tracking, Pattern, Auto-level scan);
    * Auto activation at fixed time, and can auto execute different scans and presets after a given leisure time.
    * RS485 control, integrated various of protocols, PELCO-D, PELCO-P etc.
    * 3 class lightning defend, built in 3000V lightning proof, surge resistant.
    * IP 66 outer cover with all day protection; Built-in auto thermostatic control system with patent

    Model BT-HO
    Power input DC12V~AC24V (°ņ10%)
    Power consumption Indoor°‹12W,outdoor°‹45W
    Image sensor 1/4°Ī SONY SUPER HAD CCD
    Signal mode PAL/NTSC
    Preset position 200 presets, title settable
    Accuracy °ņ0.1º
    Pan rotation range 360°„Continuous Rotation,0.5°„-240°„/S
    Tilt rotation range 90°„Vertical, 180°„Auto flip,0.5°„-220°„/S
    Control method RS485/Mancherster/BI-PHASE code
    Protocol Pelco-P/D,AD,PHILIPS etc
    Working temperature Indoor: 0ºC ~ 50ºC,Outdoor: -40ºC ~60ºC
    Ambient humidity 0-95%Non-condensing
    Shell material Aluminum
    Installation Wall, Pendant, Pole, Corner
