  1. Pan with built-in Decoder

  2. Pan with built-in Decoder

    built in decoder


    Model£ºBT-DK01
    Place of Origin: Guangdong China (Mainland)


  3. pecification:

    Electronic Indicator
    Power Input
    AC24V/220V( No identify "+"or "-")
    Power Consumption
    20W/30W( indoor/outdoor)
    Setting
    Decoder
    Built-in
    Limit Switch
    YES
    Temperature Control
    Indoor:NO,Outdoor:YES
    Left&Right Rotation Range
    Continuous 355¡ãRotation
    Left&Right Speed
    12¡ã/s
    Up&Down Speed
    10¡ã/s
    Control Method
    RS485/MANCHESTER/BI-PHASE code
    Protocol
    Various of Pelco-P/D , SAE,KALATEL,VCL,AD,PHILIPS,etc.
    Baudrate
    2400bps/4800bps/9600bps/19200bps selectable
    Work Environment
    Working Temperature
    Indoor: -5ºC ~ 45ºC£¬Outdoor: -45ºC ~55ºC
    Level of Protection
    ABS Engineering plastics, resistant water, acid rain, high temperature , rust.
    Physics
    Packing Dimension(mm)
    L280¡ÁW280¡ÁH395mm
    Camera Dimension(mm)
    L135¡ÁW65¡ÁH65mm
    Weight(kg)
    Indoor:3.0kg,     Outdoor:3.5kg
