Wireless Mini DVR Features:
* Super small size & light weight camera & DVR, very convenient to carry;
* High resolution 720X586pix(PAL),720x480pix(NTSC),480TVL camera offers good quality video;
* 4 bright LED offers 5 meters clear view in complete darkness.(LED can be turn off too);
* High capacity built-in Li-battery offers power supply for camera and DVR anywhere;
* No need any installation, and very easy to operate, just power on and it works!
* First complete wireless mini inspection camera with LED in the world!
* Portable 5-inch HD(800X480pix) DVR offers both real time and recorded videos & photos;
* Motion detect recording and loop recording available;
* Large memory available( support mini SD card up to 32GB, this package not including SD card)
* Wireless transmission offers convenience for remote view.
Mini Wireless DVR Specifications:
| Items | Value | |
| Wireless Receiving | 2.4GHz –8 channels | CH1: 2414MHz; CH2: 2432MHz; CH3: 2450MHz; CH4: 2468MHz. |
| CH5: 2490MHz; CH6: 2510MHz; CH7: 2390MHz; CH8: 2370MHz | ||
| Sensitivity | -92dB | |
| Receiving distance | 100 meters | |
| AV IN | TV system | NTSC / PAL |
| Output voltage | 3.6-4.2 V | |
| HD 5-inch LCD screen | Active area | 108mm(W) X 64.8mm(H) |
| Resolution | 800 X 480 Pixel | |
| Luminance for LCM | 200 cd/㎡ | |
| Cape clear 5-inch LCD screen | Active area | 118mm(W) X 62.8mm(H) |
| Resolution | 480 X 272 Pixel | |
| Luminance for LCM | 300cd/㎡ | |
| Video | Resolution | 720*576 / 640*480 |
| Video compress | MPEG-AVI 30fps | |
| Play format | MPEG-AVI | |
| Audio | Frequency | 20HZ-20KHz stereo |
| Earphone Output | Left: 20MW+ right 20mW [16O](suit to largest volume) | |
| Speaker | 1W | |
| Photo | Format | JPG/JPEG |
| Storage | External SD card | TF card 1GB-32GB(optional) |
| 32GB recording time | 10-32 hours | |
| 1GB photos | 15625pcs | |
| Operating system | PC | Windows & Mac OS |
| Port | USB 2.0 | |
| Language | Multiple | |
| Power | Voltage | DC 5V |
| Current(receiving mode) | 660MA | |
| Current( recording mode) | 680MA | |
| Current(recording with off-screen mode) | 340MA | |
| AC adapter | DC 5V 2A | |
| Built-in battery | Li-battery 3200mAh | |
| Standby time | Wireless record | ≥9.5 hours(off-screen); ≥5hours(on-screen) |
| Wired record | ≥12 hous(off-screen); ≥6hours(on-screen) *LED camera not included. | |
| Size (L x W x H) | 131mm x 86mm x 18mm | |
| Weight(g) | 205g | |
Mini Wireless Camera Packages:
* DVR X 1PCS(not including SD card)
* Camera x1pcs
* User manual x1pcs
* Stereo earphone x1 pcs
* USB cable x1pcs
* AC adapter x1pcs
* Back holder for installation x1 pcs
