| MODE NO. | MTV-64G22HN-ICR | MTV-64G22HP-ICR | ||
| TV SYSTEM | NTSC | PAL | ||
| IMAGE SENSOR | 1/4-inch CCD Image Sensor | |||
| CCD TOTAL PIXELS | ~ 410K | ~ 470K | ||
| SCANNING SYSTEM | 525 lines, 60 fields/sec | 625 lines, 50 fields/sec | ||
| SYNC SYSTEM | Internal / VD-Lock | |||
| MINIMUM ILLUMINATION | Typical | 1.5 Lux F1.6 | 1.5 Lux F1.6 | |
| Star light Mode | 0.05 Lux F1.6 | 0.05 Lux F1.6 | ||
| RESOLUTION | 520 TVL | 520TVL | ||
| S / N RATIO | 48dB ( MIN ) / 52dB ( TYP ) (AGC OFF£¬r=1£¬APC OFF£¬Y-OUT) | |||
| DNR (Digital Noise Reduce) | S/N UP 4.5dB | |||
| WHITE BALANCE | ATW / AWC / FIX | |||
| WHITE BALANCE RANGE | 3200 ~ 9600 ºK | |||
| B.L.C. FUNCTION | Super BLC,48 zone BLC | |||
| GAMMA CORRECTION | 0.45 /1 | |||
| AGC | AUTO (24dB max) | |||
| ALC | AUTO / FIX | |||
| IMAGE NEGATIVE | Select by OSD menu | |||
| MONTION DETECT | 48 zone (select by OSD) | |||
| FREEZE FUNCTION | Alarm in trigger or Select by OSD | |||
|
CROSS LINE |
ON/OFF Select by OSD menu (position adj. by software) | |||
| ELECTRONIC SHUTTER | AES : 1/60(1/50) ~ 1/120,000 sec. / MANUAL : 8 step | |||
| LENS | 22X optical ZOOM LENS ,F1.6~3.8,f=3.9~85.8mm | |||
| ZOOM | 220X (22X optical 10Xdigital) | |||
| FOCUS | Auto / Manual | |||
| POSITION | 64 Position (Zoom£¬Focus) | |||
| ICR (IR-CUT REMOVEABLE) | AUTO/MANUAL | |||
| VIDEO OUTPUT | Composite & Y/C output 1.0Vp-p at 75 ohm | |||
| CONTROL FUNCTION | OSD control ,Dry Switch , RS-232C/RS-485(option) | |||
| OSD LANGUAGE SELECT | ENGLISH / CHINESS_Simp / JAPANESE | |||
| OPERATION TEMPERATURE | -10¡æ TO 50¡æ | |||
| OPERATIONAL HUMIDITY | within 85©‡RH | |||
|
POWER SUPPLY |
DC12V¡À1V / 4W(Max) | |||
