800TVL HD CMOS Camera Features:
* 1/4" CMOS image sensor
* WDR, Digital noise reduction , Light suppression
* Digital high speed focus, continuous track
* Super low illumination and power consumption.
HD CMOS Camera Specifacations:
| Model No . | CET800L | ||
| Signal model | PAL/NTSC | ||
| Image sensor | 1/4" CMOS | ||
| Effective pixel | 1020(H) x 508(V) | ||
| Horizontal resolution | 800TVL | ||
| Minimum illumination | Color:0.01Lux B/W£º0.001Lux/0Lux | ||
| WDR | Yes | ||
| Sync system | Internal sync | ||
| Focus length | 3.9~85.8mm | 3.2~86.4mm | 3~90.0mm |
| Optical focus | 22X | 27X | 30X |
| Focus | Auto/manual, take high-performance DSP to realize complete digit and ultra-high speed focus function | ||
| Gain Control | Auto/Manual | ||
| White balance | Auto | ||
| Iris | Auto | ||
| S/N radio | >60dB(Enhanced) | ||
| Electronic shutter | PAL:1/50~1/10000 seconds NTSC:1/60~1/12000 seconds | ||
| Video output | 1.0Vp-p 75 ¦¸ | ||
| Power cut memory restore | Yes | ||
| Language | Chinese/English | ||
| Screen menu | AWB , Digital noise reduction , Light suppression,Mirror | ||
| Control | SONY/LG | ||
| Interface mode | Nine -pin connector | ||
| Gama modulus | 0.45 | ||
| Power supply | DC12V,90~120mA | ||
| Work temperature | -20¡ãC~+70¡ãC | ||
| Dimension | W50mmXH58mmXL90mm | ||
| Weight | 300g | ||
