Features:
* 1/2.8" SONY 1.3 Megapixel CMOS sensor
* 18x zoom, F=5-90mm, F1.6-F3.5
* AF, AE,AWB control
* International standard BT1120,SMPTE296M with YUV format, LVDS output
* Flash light auto/off/manual
* ISO: auto/manual
* Auto slowly shuttle
* ICR mode auto/manual
* Support HITAICHI interface
* Auto AWB/Sunshine/cloudy/fluorescence/night
* User defined/Auto
Specifications:
| Model | CER130NRT |
| Detail | 1.3 Megapixel 1/2.8" CMOS HD Network Movement |
| Sensor type | 1/2.8" SONY CMOS |
| Scanning system | Progressive scan |
| Signal system | PAL/NTSC |
| Minimum illumination | Color:0.05Lux @ (F1.6,AGC ON) B/W:0.01Lux @(F1.6,AGC ON) |
| S/n radio | >52dB |
| Video output | TTL |
| Resolution | 50HZ:25fps(1280x960) 60HZ:30fps(1280x960) 50HZ:25fps(1280x720) 60HZ:30fps(1280x720) |
| Focus | 5-90mm,18 times optical |
| Iris | F1.6-F3.5 |
| Horizontal viewing angle | 60-10¡ã(optics, wide-field) |
| Close distance | 1m(optics, wide-field) |
| Zoom speed | About 3.2 seconds(optics, wide-field) |
| Day and night mode | ICR filter type |
| Support agreement | TCP/IP,HTTP,DHCP,DNS,DDNS,RTP,RTSP,PPPoE,SMTP,NTP, UPnP,SNMP,FTP,802.1x,QoS,HTTPS,IPv6 (SIP/SRTP) |
| Exposure mode | Automatic exposure/Aperture-priority/Shutter priority/Manual exposure |
| Outward interface | 30pin FFC (Network port,RS485,RS232,CVBS, SDHC,Alarm in/Out,Line in/Out,Power supply) |
| Focus mode | Auto / Manual / Auto zoom |
| External communication | SONY protocol |
| Len initialization | Built-in |
| Gain | 3 degree adjustable |
| Day night mode | Auto / Color / Black and White |
| Electronic shutter | 1/1S ~1/30,000S |
| WDR | On/off |
| Backlight compensation | On/off |
| Exposure compensation | On/off |
| Dead pixel compensation | Support |
| Work environment | -20¡æ ~ 70¡æ,<90%RH |
| Power supply | DC12V¡À10% |
| Power | Static 2.5W,Dynamic 4.5W |
| Dimension(mm) | 48¡Á59¡Á85 |
| Weight | 300G |
