Your Position:Home >> Panasonic Camera > > Panasonic WV-CF284 Compact Color Dome Camera with 2x Vari-Focal Lens 540 Lines AC/DC

Related products

  1. Panasonic WV-CF284 Compact Color Dome Camera with 2x Vari-Focal Lens 540 Lines AC/DC

  2. Panasonic WV-CF284 Compact Color Dome Camera with 2x Vari-Focal Lens 540 Lines AC/DC


    Condition:New
    Model:WV-CF284



  3. The Panasonic WV-CF284 is a compact color dome camera suitable for a wide range of surveillance applications. In addition to its high resolution and low light capabilities, this camera uses a Day/Night function to switch from color to an ultra sensitive B/W mode when it gets dark, ensuring the best possible picture quality 24-hours a day. Furthermore, this camera employs an intelligent DSP system with an innovative Adaptive Black Stretch function to properly expose dark and shadowy parts of the image. The camera is fixed to the inside of the dome by a 3-hinge mechanism, allowing easy manual pan and tilt adjustments. This camera installs flat on a wall or ceiling as well as inside an existing electrical junction box.

    *  Compact and stylish design
    *  2x Vari-focal lens
    *  Day/Night function for 24-hour dependable monitoring
    *  DSP with Adaptive Black Stretch intelligently eliminates dark and shadowy portions of the image
    *  3-Hinge camera mechanism allows easy manual pan, tilt and rotation adjustments
    *  An external monitor output terminal allows service personnel to make on-site camera adjustments while viewing the results on a handheld monitor
    *  The camera installs flat on a wall or ceiling as well as inside an existing electrical junction box
    *  Operates on AC or DC power

    Specifications:

    *  Signal System:  NTSC
    *  Image Sensor:  1/4" Color CCD
    *  Lens
        Focal Length: 2.8-6mm
       Zoom: 2x
       F Number: F1.4-1.8, close
       Focus Range: 1.2m to infinity
    *  Number of Pixels:  768 x 494
    *  Horizontal Resolution:  540 Lines
    *  Angle of View
         Horizontal: 72.6-35.6¡ã
        Vertical: 54-26.7¡ã
    *  Lux:  0.9 Lux
    *  Signal-to-Noise Ratio:  50 dB
    *  Controls
        Day/Night
       Adaptive Black Stretch (DSP)
       Auto White Balance
    *  Iris Operation:  Auto
    *  Pan Angle:  +180 ~ -140¡ã
    *  Tilt Angle:  +/-75¡ã
    *  Signal Connectors:  BNC x1 (plus 1 external BNC monitor output terminal)
    *  Sync System:  Internal and VD2
    *  Power Requirements:  12 VDC or 24 VAC
    *  Power Consumption:  DC: 220mA
    *  AC: 2.7W
    *  Operating Temperature:  14 - 122¡ãF (-10 ~ +50¡ãC)
    *  Diameter and Height:  5.1 x 3.7" (129.5 x 93mm)
    *  Weight:  1 lb (460 g)
