  1. O series outdoor Intelligent Low Speed Dome Camera

  2. O series outdoor Intelligent Low Speed Dome Camera

    Outdoor CCD low speed dome camera


    Model: BT-LO

    Place of Origin: Guangdong China (Mainland)




  3. Specifications:

    1) Outdoor low speed dome camera
    2) Pan: 0-360 tilt: 0-90
    3) 1 cruising tracks; 64 presets
    4)1/4" Sony CCD
    5) All-metal

    Key Feature:

    1) Double layer of Die-cast Aluminum sell install easily and quickly, can dissipate heat more sufficiently. Black inner shell makes sharper monitor
    2) Be compatible with common cassette mechanism of camera, like SONY, HITACHI, LG and other famous brands with high resolution
    3) Running smoothly with low speed, subwoofer noise and no image dithering
    4) 64 preset positions
    5) 1 Patrol tracking routs and 1 auto level scan routs.
    6) Variable rotation (pan 0 ~ 15º/s ;tilt 0 ~ 15º/s); Auto level scan
    7) Continuous 360 º rotations in Omni-directions no fade zone; Rotation speed can be adjusted by tilting angle of the joystick
    8) Auto flips with vertical 180 º in Omni-directions, no fade zone
    9) RS485 integrated various of protocols, PELCO-D,PELCO-P etc
    10) 3 class lightning defend, built in 3000V lightning proof, surge resistant
    11) IP 66 outer cover with all day protection; Built-in auto thermostatic control system

    Image sensor 1/4" SONY CCD
    Power supply AC24V
    Power consumption 20W
    Synchronization Internal
    White balance Auto/Manual
    Active Pixels 500 (Level) * 582 (Tilt)
    Lens F=3.3mm-99mm
    Video output BNC1.0VP-P75
    Min Illumination 0.1Lux
    Focal length F=3.25~88mm
    Iris & Zoom Auto/Manual
    Zoom Function 27X optic zoom and 12X digital zoom
    Pan rotation range 360 continuously, 0.1~15/s
    Title rotation range 90(180 auto flip) , 0.1~ 15 /s
    Control method RS485
    Protocol Pelco-P/D etc.
    Baud rate 2400bps/4800bps/9600bps/19200bps
    Present points 64
    Work temperature -40C-60C
    Installation Wall, Pendant
    Level of Protection IP66 Shell, Lightning Proof, Surge Resistant
    Packing Dimension L370mm*W330mm*H420mm
    Weight Wall Mount: 6.65kg Pendant Mount: 6.60kg
