Model: BT-LIC
Place of Origin: Guangdong China (Mainland)
Key Feature:
* ABS material for outer cover and imported Acrylic out-cover and delicate design, black inner shell can monitor much sharper.
* Be compatible with common cassette mechanism of camera, like SONY, HITACHI ,LG and other famous brands with high resolution.
* Running smoothly with low speed, subwoofer noise and no image dithering
* 64 preset positions.
* 1 Patrol tracking routs and 1 auto level scan routs.
* Variable rotation£¨pan 0 ¡« 15º/s ;tilt 0 ¡« 15º/s£©; Auto level scan
* Continuous 360 º rotations in Omni-directions no fade zone; Rotation speed can be adjusted by tilting angle of the joystick
* RS485 integrated various protocols, PELCO-D, PELCO-P etc
* 3 class lightning defend, built in 3000V lightning proof, surge resistant
Electrical specifications | |
Power Input | AC24V/2A (no identity "+" or "-") |
Power Consumption | 20W |
Settings£º | |
Decoder | Built-in |
Preset Position | 64 presets |
Left&Right Rotation Range | 360¡ãContinuous Rotation |
Left&Right Speed | 0.1¡ã£15¡ã/S |
Up&Down Rotation Range | 90¡ãVertical, 180¡ãAuto flip |
Up&Down Speed | 0.1¡ã£15¡ã/S |
Control Method | RS485 |
Protocol | Pelco-P/D etc |
Baud rate | 2400bps/4800bps/9600bps/19200bps |
Working environment£º | |
Working Temperature | Indoor£º0ºC ~ 50ºC |
Physical£º | |
Packing Dimension(mm) | L260mm*W230mm*H260mm |
Weight (kg) | Surface Mount: 2.6 Kg In-ceiling Mount: 3.44 Kg |
