    CCD High Speed Dome Security Camera


    Place of Origin: Guangdong China (Mainland)
    Sensor: CCD
    Style: Dome Camera
    Level of protection: IP66



  3. Specifications:

    1) high speed dome security camera
    2) 1/4" SONY SUPER HAD CCD
    3) 22x, 27x, 33x, 37x zoom
    4) CE, FCC etc
    5) All-metal;IP66

    Key features:

    1) Fast installation structure design, can install easily and quickly; Double layer of Die-cast aluminum shell and three fans design, can dissipate heat more sufficiently black inner shell, can monitor  much sharper
    2) Built in OSD menu and support inputting with Chinese or English; Display or set parameter via menu.
    3) Auto-identify various of brand cameras and auto read camera model when power on.
    4) The first designer of wide voltage in domestic, DC12V~AC24V, no need to identify °į+" or °į-"
    5) Soft address design can alter long-distance ID address code, no need manual dial-up.
    6) Show and Edit title function containing 20 English letters, can independently set the titles for camera itself Preset Position, Patten Scan, Auto-level Scan and Zone display.
    7) Auto flip with vertical 180°„ in omni-directions, no fade zone
    8) 200 preset positions and titles can be set.
    9) 4 patrol tracking routes, every can insert 32 spots
    10) 4 patterns scan routes and continuous track record of 1000 in action, time of up to 10 minutes;
    11) 4 auto levels scan routes with left & right spacing; Speed can be set.
    12) Position-indicating function, temperature indicator function (Celsius / Fahrenheit simultaneous display), information display, information inquiry function;
    13) 8 dynamic privacy zones can be setup.
    14) 8 display zones with editable title.
    15) Alarm system with 4input and 2 output channels and support the linkage (recall preset and  several of scan modes. Tracking. Pattern. Auto-level scan)
    16) Auto activation at fixed time, and can auto execute different scans and presets after a given leisure time.
    17) RS485 control, integrated various of protocols, PELCO-D, PELCO-P, KALATEL, AD, PHILIPS, SAE,  VCL etc.
    18) Built-in temperature-controlled heating system and the speed fan
    19) 3 class lightning defend, built in 3000V lightning proof, surge resistant.
    20) IP 66 outer cover with all day protection.Bulit-in ato thermostatic control system.

    Power consumption Indoor°‹12W,outdoor°‹45W
    Image sensor 1/4 inch SONY SUPER HAD CCD
    Signal mode PAL/NTSC
    Preset position 200 presets, title settable
    Accuracy °ņ0.1º
    Pan rotation range 360°„Continuous Rotation, 0.5°„-240°„/S
    Tilt rotation range 90°„Vertical, 180°„Auto flip, 0.5°„-220°„/S
    Control method RS485/Mancherster/BI-PHASE code
    Protocol Pelco-P/D,AD,PHILIPS etc
    Working temperature Indoor:0ºC ~ 50ºC,Outdoor:-40ºC ~60ºC
    Ambient humidity 0-95%Non-condensing
    Shell material Aluminum
    Installation Wall, Pendant, Pole, Corner
